Mining Chains: Our mining chains are widely used in mining industry.We use special material combined with close tolerance machining to ensure all the chains fitted properly and with great strength. We manufacture tram chains, round link mining chain,padless connector specifications,twin outboard...

Send Inquiry

Product Introduction

Mining Chains:

Our mining chains are widely used in mining industry.We use special material combined with close tolerance machining to ensure all the chains fitted properly and with great strength. We manufacture tram chains, round link mining chain,padless connector specifications,twin outboard shackles, Bl-lock connectors for mining chain,bucket clamps, standard fabricated sprockets dimensions.The main features are high tensile strength,high fatigue strength, long wear life.

Chain size dxp	d (mm)	p (mm)	a min. (mm)	b max. (mm)	Weight (kg/m)
14x50	14+/-0,4	50+/-0,5	17	48	4
18x64	18+/-0,5	64+/-0,6	21	60	6,6
19x64,5	19+/-0,5	64,5+/-0,6	22	63	7,6
22x86	22+/-0,7	86+/-0,9	26	73	9,5
26x92	26+/-0,8	92+/-0,9	30	85	13,7
30x108	30+/-0,9	108+/-1,1	34	97	18
