Class U2 Studless Open Link Chain Ship Anchor Chain For Finishing Boat
1. Variety: Grade1, Grade 2,Grade 3,ORQ,R3,R3S,R4 stud link anchor chain; studless anchor chain; buoy chain,D-type anchor shackle; Hatch-cover chain,lifting chain,kiln chain and others; DIN Standard chain; Special chain as per your requirments and their accessories.
2. MATERIAL GRADE: ANCHOR CHAIN:GRADE 2/U2, GRADE 3/U3,
MOORING CHAIN:ORQ,R3,R3S
3.Material:20Mn (CM490),30Mn(CM690)
4.Length: 25m or 27.5m or as per your request.
5. FLASH BUT WELED
6.Surface: Self Color, Black Painted, Hot Dip Galvanized
7.Relevant Certificates: ABS, BV, CCS, DNV, KR, LR, GL, NK and RINA etc.
8. Grade U2 / U3 from 12.5mm to 162mm; Grade ORQ / R3 /R3S / R4 from 58mm to 162mm
9. accessories: kenter shackle, joining shackle. anchor shackle,pear type joining shackle
buoy shackle type A, Swivel shackle
pear type link, trangle plate.
Product Specification of Open Link Chain:
| Open Link Chain Size(6×3.6D) Proof Load Weight | |||||||||
| Diameter | Size | U1 studless link anchor chain | U2 studless link anchor chain | U3 studless link anchor chain | Weight | ||||
| D(φ) | Outside length | Outside width | Proof load | Breaking load | Proof load | Breaking load | Proof load | Breaking load | 27.5M |
| L | B | ||||||||
| mm | mm | mm | KN | KN | KN | KN | KN | KN | KG |
| 12.5 | 75 | 45 | 28.75 | 57.81 | 41.2 | 82.6 | 56.4 | 112.8 | 85.41 |
| 14 | 84 | 50.4 | 34.78 | 69.93 | 51 | 101.9 | 70.76 | 141.51 | 106.55 |
| 16 | 96 | 57.6 | 47.1 | 94.72 | 66.2 | 132.3 | 92.42 | 184.83 | 139.43 |
| 17.5 | 105 | 63 | 56.35 | 113.31 | 78.89 | 157.78 | 110.55 | 221.1 | 178.35 |
| 19 | 114 | 68.4 | 66.42 | 133.57 | 93.6 | 187.2 | 130.32 | 260.64 | 217.68 |
| 20.5 | 123 | 73.8 | 77.33 | 155.49 | 108.64 | 217.27 | 151.7 | 303.42 | 229.14 |
| 22 | 132 | 79.2 | 89.06 | 179.08 | 125.4 | 250.9 | 174.4 | 349.4 | 264.49 |
| 24 | 144 | 86.4 | 105.98 | 213.25 | 149.9 | 298.9 | 207.9 | 415.8 | 341.82 |
| 26 | 156 | 93.6 | 124.38 | 250.12 | 175.4 | 350.8 | 244 | 488 | 369.94 |
| 28 | 168 | 100.8 | 144.26 | 290.08 | 203.8 | 406.7 | 283 | 566 | 427.04 |
| 30 | 180 | 108 | 165.6 | 333 | 234.2 | 467.5 | 324.9 | 649.8 | 490.98 |
| 32 | 192 | 115.2 | 188.42 | 378.88 | 265.6 | 531.2 | 369.6 | 739.3 | 559.65 |
| 34 | 204 | 122.4 | 212.7 | 427.72 | 299.9 | 599.8 | 417.3 | 834.6 | 671.52 |
| 36 | 216 | 129.6 | 238.46 | 479.52 | 336.1 | 672.3 | 467.8 | 935.7 | 707.85 |
| 38 | 228 | 136.8 | 265.7 | 534.28 | 374.4 | 748.7 | 521.3 | 1042.5 | 788.98 |
| 40 | 240 | 144 | 294.4 | 592 | 414.5 | 829.1 | 577.6 | 1155.2 | 869.36 |
| 42 | 252 | 151.2 | 324.58 | 652.68 | 457.7 | 915.3 | 636.8 | 1273.6 | 959.3 |
| 44 | 264 | 158.4 | 356.22 | 716.32 | 502.7 | 999.6 | 698.9 | 1398 | 1111.25 |
| 46 | 276 | 165.6 | 389.34 | 782.92 | 548.8 | 1097.6 | 763.9 | 1527.8 | 1152.07 |
| 48 | 288 | 172.8 | 423.94 | 852.48 | 597.8 | 1195.6 | 831.7 | 1663.5 | 1256.26 |
| 50 | 300 | 180 | 460 | 926.09 | 648.8 | 1239.6 | 902.5 | 1805 | 1360.41 |
| 52 | 312 | 187.2 | 497.54 | 1000.48 | 697.63 | 1395.26 | 976.14 | 1952.28 | 1485.61 |
| 54 | 324 | 194.4 | 536.54 | 1078.92 | 752.33 | 1504.66 | 1052.68 | 2105.36 | 1648.08 |
| 56 | 336 | 201.6 | 577.02 | 1160.32 | 809.09 | 1618.18 | 1132.1 | 2264.2 | 1715.97 |
| 58 | 348 | 208.8 | 618.98 | 1244.68 | 867.91 | 1735.82 | 1214.4 | 2428.8 | 1844.5 |
| 60 | 360 | 216 | 662.4 | 1332 | 928.8 | 1857.6 | 1299.6 | 2599.2 | 1973.29 |
| 62 | 372 | 223.2 | 707.3 | 1422.28 | 991.75 | 1983.5 | 1387.68 | 2775.36 | 2101.56 |
| 64 | 384 | 230.4 | 753.66 | 1515.52 | 1056.77 | 2113.54 | 1478.66 | 2957.32 | 2298.47 |
| 66 | 396 | 237.6 | 801.5 | 1611.72 | 1123.85 | 2247.7 | 1572.52 | 3145.04 | 2398.1 |
| 68 | 408 | 244.8 | 850.82 | 1710.88 | 1192.99 | 2385.98 | 1669.26 | 3338.52 | 2522.88 |
| 70 | 420 | 252 | 901.6 | 1813 | 1264.2 | 2528.4 | 1768.9 | 3537.8 | 2697.65 |
Products Display:
Our Package:
1). Gunny bag, inside PVC bag and outside gunny bag +pallet
2). Wooden case or pp ton woven bag
3). Others as customer required
Please feel free to contact me for getting more information:
